A correctly sized PDF can still contain an enlarged low-detail photograph. Before handing off the production file, connect each critical raster image to its original pixels, placed dimensions and the printer’s actual requirement. That check complements the file manifest and cut geometry; the file extension alone settles none of them.
Send a file manifest that names the production authority and separates supporting assets. A folder containing many files is not a controlled handoff by itself.

Record effective image detail at the intended size
A supplier asking for a higher-resolution fruit photograph needs the original image information, not merely a PDF with a different filename. Keep the label dimensions fixed while identifying which placed image requires attention. Enlarging a raster image spreads its existing pixels across a larger printed area.
Adobe's InDesign guidance distinguishes low-resolution previews from the linked original and recommends checking Effective PPI after scaling. Ask the actual receiving printer for the suitable requirement for this image and output process. A general print-resolution recommendation is not a universal approval threshold for every label, bitmap effect or code.
For a simple uncropped raster dimension, effective pixels per inch equals source pixels divided by placed inches. In an arithmetic example, 1,200 pixels across 50.8 mm means 1,200 divided by 2 inches, or 600 PPI. Across 101.6 mm, the same pixels give 300 PPI. These are calculations, not measured print quality or a statement that either output is acceptable. The diagram shows the same source information occupying two physical widths.
| Image handoff field | What to record | What the reviewer resolves |
|---|---|---|
| Original asset | Filename/revision and pixel width/height | Is this the original rather than a downloaded preview? |
| Placement | Width/height at final output and any crop | Does each axis have sufficient source detail? |
| Effective detail | Application-reported PPI or documented calculation | Does it meet the actual agreed image requirement? |
| Export | Identified production PDF and image treatment | Did export or substitution change the represented image? |
| Open action | Replacement, reduced image size or accepted limitation | Who approves the actual consequence? |
Check both axes if the image has been stretched unequally. A photograph may also look soft because of its original focus or compression even when its pixel count is high. Conversely, a low-quality screen preview can look worse than the original output asset. Keep those questions separate before demanding a larger label or buying another proof.
Replacing the original, using a smaller image area or redesigning around an appropriate vector asset are different options. Do not enlarge and resave a small bitmap and call the original detail restored. Vector text and paths require their own checks; this calculation does not validate barcode construction, small lettering, colour or cut registration. Return the selected image revision to the same file manifest used for production authority.
AI-generated packaging planning example. Orchard Loom is a fictional brand; not a customer project, production test or usable retail artwork.
Agree the deliverable before exporting
Ask the actual supplier which file type, color handling, layer arrangement and production marks it needs for this job. A vector PDF can be a useful output, but no extension guarantees that the contents meet the converter's requirements. Avoid imposing a generic export preset without knowing the receiving workflow.
Identify one production authority for each label component and revision. An editable master may accompany it for an agreed reason, such as a requested correction, while a screenshot may serve only as a visual reference. State those roles rather than leaving the supplier to infer authority from the latest attachment time.
| Manifest field | What to identify |
|---|---|
| Component | SKU, front/back/lid role and artwork revision |
| Production authority | Exact approved filename or controlled ID and intended physical size |
| Editable support | Master file and its purpose, if requested |
| Dependencies | Linked graphics, relevant color references and font-handling arrangement |
| Nonproduction references | Mockups/screenshots explicitly labeled for explanation only |
| Replacement | Superseded filename and whether the new file changes any approved scope |
| Open item | Missing dependency, owner and confirmation required before release |
This is a handoff manifest, not a preflight certificate. Keep a missing item open until the recipient confirms an acceptable resolution.
Check the package at the receiving boundary
If an editable file is requested, confirm that linked images are included or handled as agreed. A design that opens correctly on its author's computer may rely on local files that were never transferred. Ask the recipient to identify missing links or substitutions before a correction is made.
Adobe's Illustrator packaging guide describes collecting linked graphics and generating a package report, including missing-resource information. It also notes that font copying depends on licensing. That supports checking the handoff; it does not mean every printer requires an Illustrator package or that every font can be redistributed.
Where text is outlined for a production output, retain the authorized editable source separately if needed by the design owner. An outlined file helps preserve shapes but does not prove that spelling, copy version or language characters are correct. Review those against the approved source before exporting.
Replace the whole affected authority deliberately
When a correction is requested, name the file being replaced and describe the changed component. Do not send a loose revised logo and expect the printer to decide which old document to rebuild. If the receiving team is making the change, agree who issues and approves the resulting production output.
Use a clear revision identifier rather than final-final. Preserve older material as history outside the active handoff, and make the replacement instruction visible to the recipient. A checksum can help identify an exact transferred file where both parties use one, but it does not substitute for content approval.
Keep file receipt separate from print approval
Ask for confirmation of the received set and any unresolved preparation issues. That confirmation means the files arrived and were identified; it is not proof of color, die-cut fit or label performance. The later proof should identify the actual production authority and the question being approved.
For that next step see proof scope, cut-path planning and color-reference planning.
Short answer
Confirm the receiving printer's file requirements, then supply the agreed production output with identified size, cut path, bleed, safe area and supporting assets. Confirm color and font handling for that workflow; the filename alone does not establish print readiness.
Artwork file checklist
| Item | What to prepare | Why it matters |
|---|---|---|
| File type | Vector PDF or AI file. | Keeps logo, text, lines and dielines sharp. |
| Bleed | Artwork extends beyond the trim line. | Prevents thin white edges after cutting. |
| Safe area | Important text and codes stay away from the cut line. | Protects readable copy from small cutting movement. |
| Fonts | Outlined text or packaged fonts. | Prevents unwanted font substitution. |
| Images | High-resolution product images or illustrations. | Prevents fuzzy fruit, bottle, logo or background graphics. |
| Dieline | Separate cut line for custom shapes. | Clarifies label shape, rounded corners and seal strips. |
Why bleed and safe area matter
Labels are cut after printing. Even with controlled production, tiny movement can happen. Bleed gives the design extra artwork beyond the final edge. Safe area keeps important text, barcode, QR code and logos away from that edge. This is especially important for round labels, small spice labels, lid labels and custom die-cut shapes.
PDF, AI, JPG or Canva export?
A print-ready vector PDF or AI file is usually easiest to review. A JPG or PNG can help show layout direction, but it often lacks editable text, vector lines and sharp dielines. If artwork is exported from an online design tool, send the highest-quality PDF available and keep all text readable at final size.
What to confirm before final proof
| Field | Requirement to confirm |
|---|---|
| Size | Exact label width, height and shape. |
| Material | Paper, BOPP, PET, clear film, white film or textured stock. |
| Finish | Matte, gloss, special paper or premium finish direction. |
| Use | Dry shelf, refrigerated, wet bottle, oily jar or freezer packaging. |
Related guides
Use the artwork guidelines before sending files, compare Pantone vs CMYK label printing for color planning, and review custom die-cut labels if the label has a special shape.
Send the relevant project details
Resolve the specific label handoff
Include intended label dimensions, original image pixel dimensions, placed image size and the receiving printer’s file requirement.
Prepare the label specification inquiry. The contact page opens an email draft for review; send files through the listed email or WhatsApp route. Actual supply scope, samples, pricing and timing require project confirmation.
